Android Sms Gateway Server Webhook: In-Depth Guide

Android sms gateway server webhook is the backend half of two-way and DLR: a public HTTPS URL you own, signed POSTs, and a unique constraint on event id. Product page: webhooks. API spoke: API webhook in-depth.

Live contract: Developer Center. You bring the phone and airtime. We meter devices and volume.

Your server is the subscriber

Register at POST /api/v1/webhooks. The control plane POSTs JSON. The Android does not open a hole in your VPC — you publish a URL the plane can reach.

A 200 you return after enqueueing work is enough. A 500 makes us retry. Retry plus a non-idempotent handler is how you double-text.

HMAC headers

X-SmsGateway-Signature = v1=hex(HMAC-SHA256("{timestamp}.{body}", secret)). Timestamp is X-SmsGateway-Timestamp (unix seconds). Deduplicate on X-SmsGateway-Event-Id. HMAC background: RFC 2104.

Illustrative delivered payload:

{
  "id": "evt_01K2F8QW3N4RXB7M",
  "type": "message.delivered",
  "createdAt": "2026-08-12T14:04:09Z",
  "apiVersion": "2026-08-12",
  "data": {
    "message": {
      "id": 41823,
      "number": "+14155552671",
      "text": "Your verification code is 481920",
      "status": "Delivered",
      "campaignId": 17,
      "deviceId": 3,
      "metadata": { "orderId": "1234" },
      "sentAt": "2026-08-12T14:04:02Z",
      "deliveredAt": "2026-08-12T14:04:09Z"
    }
  }
}

PHP receiver sample

<?php
header('Content-Type: application/json');

$secret = getenv('SMS_GATEWAY_WEBHOOK_SECRET');
$timestamp = $_SERVER['HTTP_X_SMSGATEWAY_TIMESTAMP'] ?? '';
$sigHeader = $_SERVER['HTTP_X_SMSGATEWAY_SIGNATURE'] ?? '';
$eventId = $_SERVER['HTTP_X_SMSGATEWAY_EVENT_ID'] ?? '';
$body = file_get_contents('php://input');

if ($timestamp === '' || $sigHeader === '' || $secret === '') {
    http_response_code(400);
    echo json_encode(['error' => 'missing_signature']);
    exit;
}

if (abs(time() - (int) $timestamp) > 300) {
    http_response_code(401);
    echo json_encode(['error' => 'stale_timestamp']);
    exit;
}

$expected = 'v1=' . hash_hmac('sha256', $timestamp . '.' . $body, $secret);
$ok = false;
foreach (preg_split('/\s+/', $sigHeader) as $candidate) {
    if (hash_equals($expected, $candidate)) {
        $ok = true;
        break;
    }
}
if (!$ok) {
    http_response_code(401);
    echo json_encode(['error' => 'bad_signature']);
    exit;
}

// Deduplicate on X-SmsGateway-Event-Id (retries and replays reuse it).
$data = json_decode($body, true) ?: [];
$type = $data['type'] ?? '';
$message = $data['data']['message'] ?? [];

if ($type === 'message.received') {
    $from = $message['number'] ?? '';
    $text = $message['text'] ?? '';
    error_log("Inbound SMS $eventId from $from: $text");
}

http_response_code(200);
echo json_encode(['ok' => true]);

C# pattern lives with C# samples. PHP: PHP samples. Those are REST examples, not a packaged SDK product.

Event handling

Retries are not new events

Same event id ⇒ same row. If you auto-reply, that outbound send needs its own Idempotency-Key. Idempotent send · duplicate sends.

Public HTTPS, not localhost

ngrok for staging is fine. Production needs a stable cert and a secret in env — never in the APK. API keys in env.

Webhooks are not SMS credit

Callbacks are HTTP. Radio sends still burn operator airtime and platform volume. Free: 300 SMS lifetime. Developer: 25,000/year. Starter/Pro/Business uncap platform volume, devices 2/5/15. Pause on Free/Developer at allowance. No unlimited carrier SMS.

Pricing.

Checklist

• Signature + timestamp window + event-id unique index.
• 200 after persist; heavy work async.
• Inbound STOP vs operational keywords written down.
• Webhook secret rotated like the API key.

Next steps

Point staging at the PHP sample, send one OTP, confirm delivered + received events once each. Two-way SMS.
